Factory Direct Supply GRP FRP SMC Sealing Modular Fiberglass Rectangular Sectional Rain Water Storage Tank Cheap Price with UK Wras and ISO Certificate
What is GRP Water Tank? GRP water tanks is the abbreviation of Fiberglass Reinforced Plastic water tanks,are leading indSend your inquiry
|Package||Iron Tray, Wooded Tray|
|Leakage||No Leakage After Filled with Water|
|Bottom Case||U-Channel Base|
|After-Sales Service||Video Technical Support, Online Support|
|Appliance||Water Storage, Drinking Water|
|Transport Package||Exported Standard|
|Specification||1*1m, 1*0.5m, 0.5*0.5m, 1.5*1m, 2*1m|
|Production Capacity||9999999999 Pieces/Year|
What is GRP Water Tank?
GRP water tanks is the abbreviation of Fiberglass Reinforced Plastic water tanks,are leading industry and civil standard water storage equipment on the market.There are many advantages such as lightweight,strong structure,modular and sectional assembly by standard panels design. GRP tanks provide safe environment with no risk of bacteria corrosion. Also our grp water storage tank can be more easier to install and more cost saving and 1x2m grp water tank panel has no leakage and more cost saving and easy to install
Furthermore,Due to the raw material to manufacturing water tank is self-resistant to bad weather and high temperature,meaning the water tank lifespan is long.Meanwhile,all raw materials attribution decides the water tank is pliable,application wide for any specific access or needs.
1. UK WRAS And TUV and ISO ARRPOVED Food grade unsaturated polyester resin for fire fighting and driniking water grp water tank
2. Alkali free twist glass fiber roving.
3. Thickener (MgO), initiator (curing agent), cross linking agent,etc.
SIZE & WEIGHT
1. The size of FRP/GRP panel are produced by standard mould, having size 1*1m, 1*0.5m and 0.5*0.5m.1*2m and 1*1.5m
2. The panel thickness is depends on tank height.
3. The available highest height is 5 meters (Add external C channel or I- beam reinforcement is needed for 4m and 5m height).
WATER TANK HEIGHT MATCHES PANEL THICKNESS.
|Height||Bottom Board||Side 1||Side 2||Side 3||Side 4||Side 5||Top board|
|1000 mm||10 mm||10 mm||5 mm|
|1500 mm||10 mm||10 mm||8 mm||5 mm|
|2000 mm||12 mm||10 mm||8 mm||5 mm|
|2500 mm||12 mm||12 mm||10 mm||8 mm||5 mm|
|3000 mm||14 mm||14 mm||12 mm||8 mm||5 mm|
|3500 mm||16 mm||14 mm||12 mm||10 mm||8 mm||5 mm|
|4000 mm||18 mm||18 mm||14 mm||12 mm||10 mm||5 mm|
|4500 mm||20 mm||20 mm||16 mm||14 mm||12 mm||10 mm||5 mm|
|5000 mm||20 mm||20 mm||16 mm||14 mm||12 mm||10 mm||5 mm|
|Item||5 mm||7 mm||8 mm||10 mm||12 mm||14 mm||16 mm||18 mm||20 mm|
|500 x 500 mm||#||4.5 kg||4.8 kg||5.8 kg||6.7 kg||7.5 kg||8.5 kg||9.5 kg||#|
|500 x 1000 mm||7 kg||#||9 kg||11 kg||13 kg||15 kg||17 kg||19 kg||21kg|
|1000 x 1000 mm||12 kg||14.5 kg||17.5 kg||21 kg||25 kg||29 kg||33 kg||37 kg||41 kg|
|Physical properties||Standard requirement||Result|
|Tensile strength||≥60 Mpa||67 MPa|
|Bending strength||≥120 Mpa||186 MPa|
|Bending modulus||≥10 GPa||12 GPa|
|Pap hardness||≥60 HBa||64 HBa|
1.What is your advantage?
We have introduced advanced equipments with the newest technology. We can supply water tanks with 2x1m smc water tank panels, in addition to regular sizes of panels.WIth large quantity of panels in stock, we can guarantee a quick lead time and a more favorable price.
2.Do you provide installation guidance?
Yes, we can provide installation guide: installation video or installation assistance on site by our engineers.
3.How long is the delivery time?
For standard water tank less than 100m3, it would be 3-5 days; For non-standard watertank and customized water tank according to client s specific requirements, it would be 15 to 30 days.
4.What is the warranty time for your products?
The warranty time of our products is 24 months, which guarantees a good after-sale service.
5.What's the guarantee, in case the water tank breaks down?
The water tank has two year's guarantee. If it breaks down, generally speaking, our technician will figure out what the problem may be, according to client's feedback. Parts will be replaced for free if the problems are caused by quality fault.
